AM-FILTER

$99.00

Shipping not included

AM-TANK developed its own fuel filter kit called AM-FILTER. Designed to efficiently remove water from fuel; compatible with Diesel, Gasoline / Petrol and Ethanol. AM-FILTER is a cartridge filter with transparent container and removable inner cartridge. It is designed to efficiently separate water from fuel. The amount of water and impurities present is immediately visible in the transparent bowl and can be efficiently cleaned out by a valve set in the bottom of the container.

Description

Shipping not included

AM-TANK developed its own fuel filter kit called AM-FILTER. Designed to efficiently remove water from fuel; compatible with Diesel, Gasoline / Petrol and Ethanol. AM-FILTER is a cartridge filter with transparent container and removable inner cartridge. It is designed to efficiently separate water from fuel. The amount of water and impurities present is immediately visible in the transparent bowl and can be efficiently cleaned out by a valve set in the bottom of the container.

Characteristics:
Inlet/Outlet: 1″.
Max flow rate: 70 l/min.
Operating pressure: 5 bar.
Dimensions: 110 head / 245 height / 90 diameter (mm).
Operating temperature: -25 ÷ 110°C.
Filtering capacity: 10µm 5µm impurities.
The packaging includes:
No.1 Filter head with 1” connections.
No.1 Transparent container with bottom drainage valve.
No.2 Cartridge clear for Water / Dirt.
No.1 Gasket (head – transparent bowl filter).
